Additel 761A Automated Pressure Calibrator

Buy New Additel 761A Automated Pressure Calibrator – High Precision Pressure Calibration System

The Additel 761A Automated Pressure Calibrator is a powerful, fully automated pressure calibration system designed for laboratory and field professionals who demand precision, portability, and advanced functionality. Engineered with upgraded performance, faster pressure control, and enhanced connectivity, the ADT761A series delivers accurate and reliable calibration for pressure gauges, transmitters, sensors, switches, and HART devices.

With automated pressure generation up to 1,500 psi (100 bar), removable pressure modules, integrated task management, and wireless communication, the Additel 761A is an ideal solution for industrial calibration, process control, manufacturing, oil & gas, and instrumentation applications.

Key Features
Fully automated pressure generation and control up to 1,500 psi (100 bar)
Accuracy models as low as 0.01% FS
Dual removable internal pressure modules for flexible range selection
Control stability to 0.003% FS
Fast pressure generation with patented electric pump technology
Portable design for field and laboratory use
Supports two external pressure modules
Wi-Fi, Bluetooth, USB, LAN, and Ethernet connectivity
Integrated HART and PROFIBUS communication
Large 7-inch color touchscreen display
Advanced data logging and task management
ISO 17025-accredited calibration certificate included

Available Models

The Additel 761A Automated Pressure Calibrator series is available in multiple configurations to suit different calibration requirements:

ADT761A-LLP – Low pressure calibration with differential and gauge measurement
ADT761A-D – Differential pressure calibration from -13.5 to 35 psi
ADT761A-500 – Vacuum to 500 psig (35 bar.g)
ADT761A-1K – Vacuum to 1,000 psig (70 bar.g)
ADT761A-1.5K – Vacuum to 1,500 psig (100 bar.g)
ADT761A-BP – Precision barometer calibration model

Smart Calibration Performance
Designed with advanced automation features, the ADT761A simplifies complex calibration procedures while improving speed and accuracy. The built-in task documentation system stores up to 1,000 calibration tasks and supports automated functions including:

Switch testing
Auto-step calibration
Leak testing
Time-stamped data logging

HART Communication & Connectivity
The ADT761A includes a full HART communicator, allowing users to read, configure, and calibrate HART devices directly from the calibrator. Multiple communication options ensure seamless integration into modern calibration workflows:

Wi-Fi
Bluetooth
USB
Ethernet
LAN

Specifications
Pressure Range: Vacuum to 1,500 psi (100 bar)
Accuracy: Up to 0.01% FS
Display: 7” TFT color touchscreen
Battery Life: Up to 12 hours
Data Storage: >8GB
Data Logging: Up to 1,000,000 readings
Weight: Less than 17.52 lb (7.95 kg)
IP Rating: IP31
Pump Life: Over 1,000,000 cycles
Operating Temperature: 0°C to 50°C

Perfect for:
Industrial pressure calibration
Process instrumentation
Oil & gas industries
Manufacturing plants
Laboratory calibration
Field maintenance and testing
HART transmitter calibration
Differential pressure testing

Why Choose the Additel 761A?
The Additel 761A Automated Pressure Calibrator combines automation, portability, and precision into one professional-grade calibration solution. With advanced pressure control, intelligent task management, and modern wireless connectivity, it helps technicians and engineers perform faster, more accurate calibrations with confidence and efficiency.
