Bruker S1 TITAN 800 XRF Analyzer – Premium Handheld Alloy Analyzer

Bruker S1 TITAN 800 XRF Analyzer – Premium Handheld Alloy Analyzer

The S1 TITAN 800 is Bruker Corporation’s flagship handheld XRF analyzer—engineered for maximum accuracy, speed, and versatility across the widest range of applications. From light elements (Mg, Al, Si) to heavy metals (U), this unit delivers lab-grade results in seconds—anywhere you work.

Key Features
Full Elemental Range: Mg → U (light to heavy elements)
Graphene Window SDD (20 mm²): <145 eV resolution for superior sensitivity
SharpBeam™ Technology: High precision with lower power consumption
High-Speed Analysis: Up to 450 kcps for rapid results
DetectorShield™: Rugged, patented detector protection
Integrated Camera + Small Spot: Precise targeting & image capture
SMART Grade™: Automatic alloy ID with optimized test times
IP54 Rated: Built for dust, moisture & harsh environments
Wi-Fi, USB, Bluetooth, GPS: Seamless data transfer & geo-tagging

What’s Included

Grade Library with 300+ Alloy Grades (Mg- U)
Standard Alloy Programs + Light Elements
Bruker S1 Sorter Handheld XRF Analyzer Carrying Case
NEW Handheld XRF Analyzer Bruker S1 800
Software and Calibrations
Check samples appropriate to the specific calibrations

Applications & Modes

Designed for multi-industry use with flexible calibrations:

Alloy 2 (Most Popular): Fast, automatic alloy ID (incl. Mg, Al, Ti)
Alloy 29: Enhanced light-element sensitivity for advanced sorting
Precious Metals: Au, Ag, Pt, Pd + gold karat analysis
Soil & Environmental: Heavy metals + nutrients
Food Quality: Nutrient & contaminant screening
Restricted Materials (RoHS/CPSIA): Compliance testing
Mining / Geo Exploration: Mg–U elemental analysis
Limestone / Industrial Materials: CaCO₃, MgCO₃, gypsum
Maritime Sulfur (MARPOL): Fuel sulfur compliance

Why Choose the TITAN 800
Top-tier performance in handheld XRF
One device, multiple industries
Exceptional light-element detection (Mg, Al, Si)
Trusted worldwide for reliability and precision
