SciAps Z-903 LIBS Analyzer – Ultimate Handheld Multi-Element Analyzer

SciAps Z-903 LIBS Analyzer – Ultimate Handheld Multi-Element Analyzer

The SciAps Z-903 is the world’s first handheld analyzer that measures every element in the periodic table, from Hydrogen (H) to Uranium (U), all in seconds. With cutting-edge Laser Induced Breakdown Spectroscopy (LIBS) technology, the Z-903 redefines portable elemental analysis by offering unmatched precision and versatility in a single device.

Key Features:
Complete Elemental Coverage: Measures every element from H to U, including elements like Lithium, Beryllium, Boron, Fluorine, and Sodium, which cannot be analyzed by XRF analyzers.

Extended Spectrometer Range: The Z-903’s spectrometer covers 190 nm to 950 nm, allowing the measurement of previously inaccessible elements like H, F, N, O, Br, Cl, Rb, Cs, and S.

Superior Sensitivity: For Lithium (Li), it achieves limits of detection in the 2-5 ppm range. It also measures Potassium (K) with minimal interference, unlike traditional XRF methods.

Portable & User-Friendly: A compact handheld device with Android OS and app-driven software for easy operation, providing full user control over laser settings, spectrometer configurations, and calibration curves.

Advanced Micro-Analysis: The Z-903 features a 100 µm laser beam for micro-analysis in the field. This enables heat mapping of regions on rocks, providing high-resolution analysis that handheld XRF devices cannot match.

Global Applications:
Mineral Exploration: Widely used in lithium exploration, both in hard rock and brines.
Forensics & Authentication: Ideal for material authentication and forensic analysis.

Archaeology: Perfect for elemental analysis of artifacts, including trace elements that traditional methods may miss.
Oil & Gas: Used in geochemical analysis and exploration, providing fast, on-site results for elemental composition.

Benefits Over Other Analyzers:
Measuring Elements That XRF Can’t: Analyzes elements such as Lithium, Beryllium, Carbon, Sodium, and Boron, which handheld XRF devices are unable to detect.

Micro-Analysis Capability: The Z-903’s laser can raster in two dimensions, allowing for detailed mapping of elemental distribution across surfaces like rocks and soil.
Greater Sensitivity for Major Elements: The Z-903 excels in detecting low concentrations of elements such as Magnesium and Aluminum, outperforming handheld XRF in some applications.

Complete Control:
Customizable Settings: Full control over laser strike pattern, cleaning shots, and spectrometer settings via advanced software.
Quantitative Calibration: Create custom calibration curves for precise measurements in various materials.

Easy Data Management: The intuitive Android app allows for quick spectral data comparisons and result analysis.
Safety and Durability:
Laser Safety: Designed with built-in safety protocols to ensure safe operation at all times.
Rugged Design: Built for field use with a durable, portable build that can withstand challenging environments.

Product Details:
Spectrometer Range: 190 nm to 950 nm
Laser Beam: 100 µm for high-resolution analysis
Elements Detected: From H to U, including Li, Be, B, F, Na, and more
OS & Software: Android-based with app-driven software for full control and data analysis
Applications: Mineral Exploration, Forensics, Archaeology, Oil & Gas, Geochemical Analysis

The SciAps Z-903 LIBS Analyzer is the most advanced handheld analyzer on the market, providing unparalleled flexibility, speed, and accuracy for a wide range of applications. Whether you’re exploring minerals, authenticating materials, or conducting environmental analysis, the Z-903 is the ultimate tool for rapid, reliable results.

Order now and take your elemental analysis to the next level!
