SHARE 205S PRO 225MP Oblique Aerial Camera

SHARE 205S PRO 225MP Full-Frame 5-Sensor Oblique Aerial Camera – UAV Mapping Solution

Capture highly detailed, distortion-free aerial data with the SHARE 205S PRO—a powerful 225MP full-frame oblique camera system designed for professional 3D mapping and urban surveying. Engineered for seamless integration with the DJI Matrice 400, this plug-and-fly solution delivers consistent, high-quality results for digital twins and photogrammetry workflows.

Why Choose SHARE 205S PRO?
With advanced full-frame sensors and optimized 56 mm tilt lenses, this system excels at capturing accurate building facades—even in tight urban environments. Real-time exposure adjustments ensure uniform image quality, reducing post-processing time and boosting efficiency.

Key Features:

225MP total resolution for sharp, high-density data capture
Full-frame 5-sensor oblique system for complete coverage
Plug-and-Fly compatibility with DJI Matrice 400
5-channel real-time HD video monitoring
High-speed 2TB M.2 PCIe SSD for rapid data storage
Advanced 5nm image processor for consistent imaging
Durable CNC-machined magnesium alloy housing
TimeSync 2.0 support for precise positioning (GCP-free)
Long shutter life rated at 500,000 cycles

Optimized for Urban Mapping
Specialized 56 mm tilt and 40 mm nadir lenses minimize distortion and deliver accurate facade detail. Intelligent flight integration dynamically adjusts camera settings for reliable results in changing light conditions.

Technical Highlights:

Sensor: Full-frame (36 × 24 mm), 4.4 µm pixel size
Lenses: 56 mm (tilt) + 40 mm (nadir), fixed focus
Storage: 2TB M.2 PCIe SSD
Interfaces: Skyport V3.0, USB-C, Universal Aviation Plug
Compatibility: Multi-rotor & fixed-wing drones

Safety & Responsible Use
Operate in accordance with local drone regulations and airspace laws. Avoid restricted zones, respect privacy, and ensure trained operation. Designed for professional aerial surveying and mapping applications only.

Upgrade your aerial imaging with the SHARE 205S PRO—precision, speed, and reliability for every mission.
