NEW Bruker Tracer 5 Handheld XRF Analyzer Best Price for sale
Advanced, Portable Elemental Analysis
Unlock research-grade precision in the field with the Bruker TRACER 5 Handheld XRF Analyzer. Designed for researchers, conservationists, and advanced users, this portable device provides lab-quality elemental analysis—from ancient artifacts to industrial materials. With customizable settings and the ability to detect elements from Fluorine (F) to Uranium (U), the TRACER 5 offers unmatched flexibility for accurate, non-destructive testing on-site.
Key Features
Wide Elemental Range: Detect elements from F to U, including light elements, with helium purge.
Advanced Detector: Graphene SDD for <140 eV resolution.
Customizable Settings: Full control over voltage, current, filters, and collimators.
Optimized Beam Path: Switch between air and helium for improved light element analysis.
Integrated Camera: Visualize and document samples with built-in CMOS camera.
Field-Ready Design: IP54 rated, operating from -10°C to 50°C, rugged for any environment.
Seamless Connectivity: Wi-Fi, USB, and Bluetooth for easy data transfer.
User-Friendly Software: Bruker Instrument Tools (BIT) and ARTAX for detailed spectral analysis.
Applications
Archaeometry: Analyze metals, ceramics, and pigments non-destructively.
Geology & Mining: Field-based analysis of ores, soils, and core samples.
Environmental Testing: Identify heavy metals in plants and soils.
Materials Research: Measure composition in metals, semiconductors, and advanced materials.
Art Conservation: Authenticate materials and guide restoration.
Precious Metals: Verify the purity of gold, silver, platinum, and alloys.
What’s Included
Bruker TRACER 5 Handheld XRF Analyzer
Lithium-ion battery & charger
3 mm and 8 mm collimators
Integrated CMOS camera
USB drive & Wi-Fi connectivity
PC Software Suite (BIT + ARTAX)
Carrying case and user manual
Technical Specifications
Detector: Graphene SDD, <140 eV at 450,000 cps
X-ray Tube: Rhodium, 6–50 kV, 4 W max
Collimators: 3 mm & 8 mm (user changeable)
Camera: VGA CMOS, 640×480 px
Weight: 1.9 kg (4.1 lbs)
Operating Temp: -10°C to 50°C (14°F to 122°F)
Connectivity: USB, Wi-Fi, Bluetooth
Display: 3.7″ TFT touchscreen, 640×480 px
The Bruker TRACER 5 offers portable, high-performance analysis for professionals who demand precision in the field. Get advanced elemental analysis anywhere with the TRACER 5!
